NORVI Product Series Comparison
Overview Comparison
| Feature | NORVI Agent One | NORVI ENET (ESP32) | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Primary Use Case |
Low-power IoT nodes, battery-powered applications |
Ethernet-based industrial IoT with wired connectivity |
Cellular connectivity for remote locations |
Wi-Fi-based industrial IoT applications |
Target Applications |
Sensor nodes, remote monitoring, battery-operated devices |
Industrial automation with stable network, data servers |
Remote monitoring without WiFi coverage, mobile IoT |
Connected factories, smart buildings, Wi-Fi-enabled environments |
Hardware & Processing
| Specification | Agent One | ENET ESP32 | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Processor (Standard) |
ESP32-WROVER-B with PSRAM |
ESP32-WROOM32 |
ESP32-WROOM32 |
ESP32-WROOM32 |
Processor (Low Power) |
STM32L series (ARM Cortex-M3) |
N/A |
N/A |
N/A |
Flash Memory |
4MB |
4MB |
4MB |
4MB |
RAM |
520KB SRAM + PSRAM |
520KB SRAM |
520KB SRAM |
520KB SRAM |
ROM |
448KB |
448KB |
448KB |
448KB |
Clock Speed |
Up to 240 MHz |
Up to 240 MHz |
Up to 240 MHz |
Up to 240 MHz |
Low Power Features |
Ultra-low power STM32L variants, transistor outputs for sensor power control |
Connectivity Options
| Connectivity | Agent One | ENET ESP32 | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Wi-Fi |
Built-In (ESP 32 Modules |
Built-In |
Built-In |
Built-In |
Bluetooth |
BLE |
BLE |
BLE |
BLE |
Ethernet |
W5500 (10BaseT/100BaseTX) |
W5500 |
W5500 (select models) | |
Cellular (2G/3G/4G LTE) |
Available with LTE add-on |
SIM7500 or EC25 modem | ||
LoRa |
Available with LoRa add-on | |||
NB-IoT |
Available with NB-IoT add-on | |||
RS-485 |
(varies by model) |
Input/Output Capabilities
| I/O Type | NORVI Agent One | NORVI ENET (ESP32) | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Digital Inputs |
Varies by model (typically 2-6) |
8 inputs (18-32V DC) |
8 inputs |
Varies (typically 4-8) |
Analog Inputs |
0-10V (varies by model) |
4 inputs (0-10V, 16-bit ADS1115) |
0-10V / 4-20mA options |
0-10V / 4-20mA options |
Relay Outputs |
Available on select models |
N/A (ENET-AE06-V model) |
Available (typically 6-8) |
Available on select models |
Transistor Outputs |
With power control for sensors |
N/A |
Available |
Available |
Input Voltage Range |
18-32V DC |
18-32V DC |
24V DC |
24V DC |
Maximum Switching Frequency |
N/A |
1 kHz |
N/A |
N/A |
Features & Peripherals
| Feature | NORVI Agent One | NORVI ENET (ESP32) | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Display |
Pixel RGB LED indicator |
0.96″ OLED (SSD1306) |
0.96″ OLED |
0.96″ OLED |
Buttons |
Front panel button |
Front panel button |
Multiple buttons | |
microSD Card |
SPI interface | |||
RTC (Real-Time Clock) |
DS3231 with CR2032 backup |
DS3231 |
DS3231 | |
External Antenna |
SMA connector |
For cellular | ||
Expansion Port |
Limited |
10-pin with I2C, UART, power |
Physical & Environmental
| Specification | NORVI Agent One | NORVI ENET (ESP32) | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Mounting |
DIN-Rail |
DIN-Rail / Mounting tabs |
DIN-Rail |
DIN-Rail |
Enclosure |
Compact |
NORVI 204 |
Standard industrial |
Standard industrial |
Dimensions |
Compact form factor |
90.5 × 60.6 × 56.6 mm |
Standard |
Standard |
IP Rating |
IP20 |
IP20 |
IP20 |
IP20 |
Operating Temperature |
-10°C to +85°C |
-10°C to +85°C |
-10°C to +85°C |
-10°C to +85°C |
Operating Altitude |
0-2000m |
0-2000m |
0-2000m | |
Shock Resistance |
N/A |
15 gn for 11ms |
N/A |
N/A |
Power Requirements
| Power Spec | NORVI Agent One | NORVI ENET (ESP32) | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Supply Voltage |
12-24V DC (varies |
24V DC |
24V DC |
24V DC |
Current Consumption |
Low (varies by variant) |
400mA typical |
Higher (due to cellular modem) |
300-500mA |
Recommended Power |
Battery or 12-24V 1A |
24V DC 1A |
24V DC 1-2A |
24V DC 1A |
Battery Operation |
Optimized for battery use |
Programming & Software
| Feature | NORVI Agent One | NORVI ENET (ESP32) | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Programming Interface |
Mini USB |
Mini USB |
Mini USB |
Mini USB |
Supported IDEs |
Arduino IDE, ESP-IDF |
Arduino IDE, ESP-IDF |
Arduino IDE, ESP-IDF |
Arduino IDE, ESP-IDF, Soapbox Snap, Rapid SCADA |
Protocols Supported |
MQTT, HTTP, Modbus RTU |
MQTT, HTTP, Modbus RTU, TCP/IP, UDP |
MQTT, HTTP, Modbus RTU |
MQTT, HTTP, Modbus RTU |
OTA Updates |
Over Wi-Fi |
Over Wi-Fi/Ethernet |
Over Wi-Fi/Cellular |
Over Wi-Fi |
Certifications & Compliance
| Certification | NORVI Agent One | NORVI ENET (ESP32) | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
EN 61131-2:2007 | ||||
EN 61010-1:2010+A1:2019 | ||||
EN IEC 61010-2-201:2018 |
Annex III, Part B, Module C | |||
ESD Protection |
Standard |
4kV contact / 8kV air |
Standard |
Standard |
EMI Resistance |
Standard |
10V/m (80MHz-1GHz) |
Standard |
Standard |
Expansion Capabilities
| Expansion Type | NORVI Agent One | NORVI ENET (ESP32) | NORVI GSM | NORVI IIOT |
|---|---|---|---|---|
Analog Input |
I2C-based expansion | |||
Digital Input |
I2C-based expansion | |||
Analog Output |
I2C-based expansion | |||
Transistor Output |
I2C-based expansion | |||
Relay Output |
I2C-based expansion | |||
Communication |
LoRa, NB-IoT, LTE |
Limited |
N/A (built-in) |
Ethernet, RS-485 |
Pricing Range
| Product | Approximate Price Range (USD) |
|---|---|
Agent One |
$45 – $95 (varies by variant and connectivity) |
ENET ESP32 |
$70 – $120 (varies by I/O configuration) |
GSM |
$90 – $206 (varies by cellular modem and I/O) |
IIOT |
$65 – $130 (varies by I/O configuration) |
Key Differentiators
Agent One
- Best for: Battery-powered applications, ultra-low power requirements.
- Unique features: STM32L low-power variants, transistor outputs for sensor power management, modular connectivity (LoRa/NB-IoT/LTE add-ons).
- Ideal scenarios: Remote sensor nodes, agriculture monitoring, wildlife tracking.
ENET ESP32
- Best for: Reliable wired connectivity in industrial settings.
- Unique features: W5500 Ethernet with 8 independent sockets, hardware TCP/IP stack.
- Ideal scenarios: Factory automation, building management systems, stable network environments.
GSM
- Best for: Remote locations without WiFi coverage
- Unique features: Cellular connectivity (2G/3G/4G LTE), redundant. communication paths (WiFi + Cellular + Ethernet).
- Ideal scenarios: Agricultural monitoring, infrastructure monitoring, mobile equipment tracking.
IIOT
- Best for: WiFi-enabled industrial environments.
- Unique features: Balanced feature set, wider IDE support, OPC server compatibility.
- Ideal scenarios: Smart factories, connected buildings, IoT gateways.
Model Naming Convention
Example: NORVI ENET-AE06-V
- ENET: Product series
- AE: Analog and Ethernet
- 06: 6 total I/O points (4 analog + 2 reserved)
- V: Voltage inputs (0-10V)
Other suffixes:
- I: Current inputs (4-20mA)
- R: Relay outputs
- T: Transistor outputs
- G: GSM 2G modem
- L: LTE modem
- ES: ESP32 variant
- SI: Standard industrial
Note: Specifications may vary by specific model variant. Always refer to individual datasheets for precise specifications. This comparison is based on available documentation as of the knowledge cutoff date.
